- Precision Grade Performance Tools
- The Number 1 Choice Of Tradesman Worldwide
- Comfortable In Use And Quality Assured Design
- Fit To Match The Needs In The Shop, At Home Or In The Service Field
- Each Tool Is Proven And Tested For Durability And Function In Real World Use And Conditions
Product Description
Made In Wuppertal-Cronenberg, Germany. In Addition To Quality, Innovation And Performance, Other Important Cornerstones Are Sustainable Actions And Value-Guided Orientation.
Amazon.com
20 percent reduction of hand force due to high leverage power joint (view larger).
The 10-inch Knipex angled diagonal cutter (model 74 01 250) is ideal for tough, continuous use. Easy to use, it offers high-leverage axel design with a 20 percent reduction in required force compared to conventional cutters of the same length for reduced fatigue. It features optimum coordination of the cutting edge angle, transmission ratio, and ergonomic handle shape, and it easily cuts nails and all types of wire with high-performance precision. This 12-degree angled version has a 2-1/2-inch hand clearance and cuts objects to a near flat finish.
Designed for cutting harder wires and materials, the 10-inch diagonal cutter is unique to Knipex, providing up to 25 percent more cutting power than the 8-inch model. Its longer size also allows for reaching into confined spaces.
Forged from oil-hardened chrome vanadium steel, it's built to last. The fixed forged axle rivet joint assures continuous smooth operation with no weakening or wobbling effect over time. The precision matched, induction-hardened cutting edges cut a wide range of materials — from soft copper and aluminum to hardened materials like nails, piano wire, or ACSR wire without changing tools or damaging the cutting edges. It's completed with heavy duty plastic-coated handle grips.
Suitable for all types of wire including piano wire (view larger).Quality in Every Detail
Sometimes we give our pliers a really hard time. We try to destroy them to find out what makes them good and long-lasting. Because we don't want to leave anything to chance, we take a long, careful look.
The steel Knipex uses is precisely hardened with a maximum of 0.8 percent carbon and defined parts of chromium and vanadium, guaranteeing optimum cutting performance and service life — even though it requires special production and costs a bit more. But our high product demands require this.
The rivet of our high-leverage diagonal cutter also has to stand up to a lot of stress. That's why we literally give it backup: we forge it straight onto the pliers. This means extra effort as we have to precision mill the rivet to a few hundredth millimeters. But satisfied users are worth this effort.
Knipex also looks closely at the small details. The angles, the sharpness, the hardness, the toughness of the cutting edges. The precision and smooth movement of the joint. The handle design and the finish. We keep reviewing these subjects, we research, we test, and we improve our pliers.
About Knipex
Headquartered in Wuppertal, Germany, Knipex is an independently-owned family enterprise steeped in tradition and specializing in the manufacturing of high-quality pliers. It all started back in 1882 when C. Gustav Putsch set up his own forge shop in Cronenberg (now a suburb of Wuppertal), and the company is now run by a fourth generation of that family. The world's leading brand in pliers today, Knipex is focused on the performance, service life, and ergonomics of its tools in order to meet the high expectations of professional users.
74 01 250 High Leverage Diagonal Cutters, 10-Inch
At a Glance
- High-leverage cutting performance with minimum effort
- 12-degree angled head to prevent knuckles from scraping
- Fixed forged axle rivet for heavy duty use
- Cuts piano wire, ACSR, nails, and other hard wire
- Precision cutting edge hardness of 64 HRC (approximate)
- Chrome vanadium heavy-duty steel, forged and oil-hardened
See larger image.
Specifications
- Cutting capacity: Up to 3/16-inch nail and wire pin; 9/64-inch wire rope strand and steel wire; 1/8-inch spring steel wire
- Length:10 inches
- Weight: 13.8 ounces
- Handles: Plastic coated
From the Manufacturer
High leverage diagonal cutters with a 12 degree angled head require 21% less effort. The 12 degree angled head for flush cutting provides space of approximately 70 mm clearance for gripping. The high cutting performance is due to optimum co-ordination of the cutting edge angle, transmission ratio and the ergonomically handle shape. The precision cutting edges are induction hardened to approximately 64 HRC and will cut medium hard wire up to 4.6 mm; hard wire up to 3.5 mm and piano wire with maximum 2.5 mm diameter. The forged-on axle offers a high level of stability for heavy use and long service life.
